Very-Clear™ Pool Glass
RIGI Premium Wall Mounted Joiner - Side Fix
- Availability:
- In Stock
- Pick-up, Shipping or Packing:
- Calculated at Checkout
- NEED AN ASAP PICKUP? (M-F 8-3 AEST):
- Note ideal latest time in Order Notes & Text 0412 736 242. We'll aim to meet it!
- ASAP IN-STOCK GUARANTEE:
- If it's not all in stock, you may cancel for a full refund
- Stocked At:
- Bris (Virginia), Ipswich (Bundamba), G-Coast (Molendinar), N-castle (Cardiff), Melb (Derrimut & Dandenong), Adelaide (Kilburn), Perth (Jandakot). Not collecting here? Order separately; select 'Boxed Item Pack & Send'
- CLICK & COLLECT (FREE):
- Order now, pick up within 30 days. Ready-to-collect notice in 1–3 days
- DIRECT DELIVERY ($159-$229):
- In 3-10 days in the stocking warehouse delivery zone
Description
- Friction fit clamp – no holes needed in your glass
- Offset leg side-fixes to brace glass to walls or posts
- Can be installed after the fence is finished
- 1 x side-fixed countersunk fixing hole**
- Made from quality 316 stainless steel
- Suits 12mm glass panels
The biggest advantage of this bracket is that it can be installed after the fence is finished. Get all your glass aligned and your gates hinged, and only once you are sure the fence is perfect do you fit the offset bracket and attach it to the side. It is also the answer when it simply does not suit to mount the standard in-line wall joiner face-on to a wall – this frameless pool glass bracket shifts the mounting fixing to the side of the glass line, so you can fix off to the side of the fence line instead. It is a popular way to brace a panel for extra support, and a favourite option for bracing high retaining-wall panels.
It grips the glass with the same no-drill friction fit – grub screws driving an internal pressure plate with rubber – so there is no need to lift or re-set panels: position it, tighten, done.
As Fence Guru, we supply the original RIGI clamp – a premium finish appropriate to a professional-quality frameless glass pool fence.
Fence Guru tip: Recommended gap is 20mm to 50mm from the wall face. This keeps the glass aligned while the clamp holds a firm grip on your 12mm toughened glass.
Good to know: all RIGI clamps are fully reversible, so the clamp can be flipped to suit whichever way your clamp needs to sit.
A note on tightening: As with spigots and other friction fit glass hardware, tighten firmly but do not overtighten.
**Available in Brisbane, Gold Coast, Newcastle, Melbourne, Adelaide and Perth but not stocked at every warehouse.
Availability: Part of our range stocked across 8 Aus-wide warehouses for collection: Brisbane (Virginia), Ipswich (Bundamba – opening soon), Gold Coast (Molendinar), Newcastle (Cardiff), Melbourne (Derrimut & Dandenong), Adelaide (Kilburn) and Perth (Jandakot). If you are not collecting your main order from one of these locations, please order your RIGI clamps as a separate order and select the “Boxed Item Pack & Send” shipping option at checkout.
RIGI Clamp Gap Chart
| RIGI Clamp Option | Bracket Length | Recommended Gaps |
|---|---|---|
| Inline – Small | 75mm | 20–35mm (40mm max) |
| Inline – Large | 140mm | 20–60mm (90mm max) |
| 90 Degree Corner | 72mm × 45mm | 20–35mm (gap on 72mm side only) |
| Adjustable – set at 90° (large corner) | 102 × 102mm | 32–60mm (per side, measure from outside glass line) |
| Adjustable – straight, angled, 135° | 180mm | 55–90mm |
| Wall Mount – Inline Fix | 80mm | 20–60mm |
| Wall Mount – Offset / Side Fix | 70mm | 20–50mm |
All RIGI clamps suit 12mm glass and are typically installed 100mm below the top of the glass fence. Gap = the space between the two glass panels (or glass and wall/post). Stay within our recommended range for a professional, strong and best-looking result.
Stainless steel maintenance:
Clean stainless steel regularly using a mild detergent and a soft brush to remove the build up of dirt, grime and salt deposits etc. Wash with a mild detergent and then rinse off with fresh water. Do not use heavy duty cleaners or strong household cleaner or solvents. Never use hydrochloric acid to clean stainless steel or cleaners that are acidic or alcohol based. Please note: if you are in a highly corrosive environment and choose not to regularly clean your stainless steel components you may get tea staining/discolouration on your stainless steel products.
